“真實世界”的油耗和排放測試已經逐漸成為廠商新車/動力系統評估的重中之重，但也同時給這個本已相當復雜的領域帶來了新的挑戰和潛在經濟負擔。長久以來，虛擬測試一直都是汽車開發的重要組成部分，可以為控制成本做出巨大貢獻，但這種技術在協助廠商滿足“真實世界駕駛排放（RDE）”的合規要求方面是否真的有效，仍是人們的主要擔憂之一。
英國專業軟件公司rFpro在虛擬道路和賽道測試方面擁有豐富的經驗，這家公司旨在協助廣大型汽車廠商利用虛擬工具，開展真實世界駕駛排放測試。（閱讀相關文章：用于輔助自動駕駛汽車的路面建模技術）
rFpro公司的技術總監ChrisHoyle指出，廠商可以借助一款駕駛模擬系統，建立一個讓駕駛員完全沉浸其中的完整虛擬環境，從而實現更加全面的在環測試（DIL）。Hoyle聲稱，在這種測試環境下，車輛可以對駕駛員的行為做出反應，這在以前是無法實現的。
“只要使用得當，虛擬測試工具可以協助汽車廠商在汽車研發的早期階段做出一些關鍵選擇，從而避免無謂地投入大量資金。”Hoyle告訴《汽車工程雜志》記者，“過去，新車的排放測試通常在真實賽道進行，測試結果也常因駕駛員的不同而產生巨大差異。如今，這種測試已經被RDE技術所取代，而虛擬測試工具也在這里找到了新的用武之地。”
Hoyle表示，RDE測試并不能排除駕駛員和路況對測試結果的影響。然而，通過選擇更多水平不一、習慣不同的駕駛員進行測試，廠商可以更加全面地掌握車輛在不同條件下的行為，從而為未來的新車驗收測試積累更多信心。于此同時，這將為廠商節省大量經濟和時間成本。
Hoyle表示，“我們的一個客戶估計，借助DIL模擬器將汽車研發后期的一些測試環節提前進行，并根據測試結果及時進行調整，可以節約超過30%的相關成本。”
早在許多年前，虛擬測試技術就已經得到了大家的認可。如今，這種技術可以更加廣泛地適用于更多領域，為應用的性能測試提供一個沒有天氣或交通狀況干擾的可重復測試環境。Hoyle解釋說，“盡管虛擬測試也會對人類駕駛員的行為做出反應，但如果人類駕駛員在虛擬場景中的行為和反應并非與現實世界一模一樣，這種虛擬測試幾乎沒有什么價值。”
在常規的汽車研發項目中，為了在RDE測試階段之前，確保車輛可以實現設計性能，廠商可能需要負擔大量的額外開支。為了優化對車輛的校準，深入理解一些與駕駛員行為有關的因素非常重要，比如有些駕駛員在巡航時的節流調速水平不高，又或是不能及時預判前方車流減速等。
通過道路測試量化車輛排放與駕駛員駕駛習慣之間的關系十分耗時耗力，非常困難。Hoyle聲稱，rFpro公司開發的DIL模擬器可以參考駕駛員的典型行為，創造一個足夠真實的虛擬測試環境。他說，這款模擬器可以協助廠商對汽車的虛擬排放性能有更全面的把握。人類駕駛員手握這款模擬器就可以取得與“真實世界駕駛測試接近的測試結果。”
過去的駕駛模擬器通常對駕駛員行為的反應太慢，無法創造一個足夠真實的環境，引領駕駛員做出與“真實世界”中完全相同的“真實”反應。但借助最新一代的細微動作捕捉平臺，rFpro設計的軟件可以提供毫無延遲的反應速度、超高分辨率的逼真畫質，以及擁有弧度、坡度、起伏和坑洼等一系列豐富細節的道路模型，從而為使用者提供Hoyle口中的“前所未有的真實”體驗。
通過rFpro公司的虛擬測試工具，汽車廠商可以對車輛“受人類駕駛員影響”和“由電腦控制”的因素加以區分并單獨處理。
作者：Stuart Birch
來源：SAE《汽車工程》雜志
翻譯：SAE中國辦公室
New virtual tools tackle real-world emissions testing
“Real-world” fuel consumption and emissions testing is becoming central to OEM new car/new powertrain programs. But it brings new challenges and potentially financial headaches to a highly complex area. A major concern is the efficacy of virtual testing—long established as part of vehicle development and a huge contributor to cost saving—in meeting real world driving emissions (RDE) legislation requirements.
Helping to achieve that is the aim of U.K. software specialist rFpro, which has extensive experience in virtual road and track (via F1) testing; seehttp://articles.sae.org/14181/ and http://articles.sae.org/13603/.
Chris Hoyle, rFpro’s Technical Director, states that creating a fully convincing virtual environment, in which a driver feels totally immersed, enables driver-in-the-loop (DIL) testing with a driving simulator to be applied, for what he claims as the first time, in areas where human reaction to a situation affects the vehicle’s behavior.
“Used effectively, virtual testing enables critical decisions to be made early in an automotive engineering program and certainly long before any commitment to significant financial investment," Hoyle told Automotive Engineering. "One such area, not previously associated with simulators, is emissions testing because when RDE tests take the place of today’s artificial rolling road test cycles, variations between different drivers will significantly influence the results obtained.”
RDE tests will be influenced by driving style and road conditions, said Hoyle. But the capability to evaluate the vehicle’s behavior under repeatable laboratory conditions using drivers of different abilities and with different habits in order to maximize confidence ahead of approval testing, can provide a massive saving in costs and time.
“One of our clients estimates that over 30% of the costs incurred in developing driving attributes could be saved by frontloading the engineering activity on a DIL simulator with subjective feedback,” he noted.
Virtual technology testing has been accepted for many years, its scope having broadened to embrace evaluation of the effects of a very wide range of areas under repeatable conditions, without weather or traffic variations. However, where human driver input is required, virtual testing "is of little value unless that driver responds to the test scenario in exactly the same way as he or she would do in a ‘real world’ situation,” explained Hoyle.
The need to ensure, in advance, that a vehicle will achieve the target results during RDE testing threatens to add significant additional cost to the typical development program. Understanding driver influenced variables, such as poor throttle modulation when cruising, or failure to anticipate traffic ahead reducing speed, will be central to optimizing the calibration of the vehicle.
Quantifying the influence of driving habits on vehicle emissions is difficult and time consuming using on-road testing. Software developed by rFpro for DIL simulators creates a sufficiently high level of realism that drivers behave in a representative way, claims Hoyle. He said this gives manufacturers the necessary confidence that a car’s virtual emissions performance, in the hands of a human driver using the simulator, "will be equivalent to its ‘real world’ results.”
Historically, driving simulators have reacted too slowly to driver input to create the realism necessary to trigger driver behavior that is fully representative of ‘real-world’ driving. But when used with the latest generation of lighter motion platforms with faster responses, rFpro’s software is designed to provide what Hoyle regards as “unprecedented realism” via use of lag-free, high resolution graphics and finely detailed road surface models including cambers, gradients, bumps and potholes.
This allows vehicle manufacturers to identify and isolate those aspects of human driving which differ significantly from computer controlled operation.
Author: Stuart Birch
Source: SAE Automotive Engineering Magazine
多位軟件專家認為，逼真的虛擬技術是真實世界駕駛排放測試（RDE）領域的下一個前沿課題。
rFpro公司的技術總監Chris Hoyle表示，過去，真實世界駕駛排放測試并不在模擬器的工作范圍之內。
